New-57 Inch EC Motor Plastic Shell Butterfly Fan

Inquire Now

Add to Inquiry Basket

Last Product

Description

●Aerodynamic Fan Design：Injection-molded composite plastic shell, delivering large air volume, high efficiency and strong corrosion resistance.

●Customized High-performance Motor：Self-developed EC motor variable frequency direct-drive motor; stable speed, strong load capacity; supports 0-10V/RS485 dual control; IP66 protection & Class F insulation for harsh environments.

●Innovative Butterfly Panel：Premium spray-coated galvanized valve plate ensures high strength, no deformation and excellent sealing; balances large air volume with reliable operation.

Model

Air

volume

（m³/h）

Rated

power

（kW）

Speed（rpm）

voltage

（v）

Rated Current
（A）

Blade material

Size W*H*T(mm)

Energy Efficiency Ratio
m³/h/w

GFM-2XM57EC

（57 inch plastic shell buttefly fan）

67800

2.2

690

380

2.24

3 PAG

1399*1399*1433

48.7

61300

620

1.70

50.8
